HX-007 Automatic Ultrasonic Plastic Tube Sealing Machine
◎ Adopts ultrasonic sealing technology, no need warm up time, more stable and neat sealing, no distortion and low reject rate less than 1%.
◎ Manually feed the tube, press start button, machine could automatically identify the registration mark, sealing (with coding), end trimming.
◎ Independent R &D for digital ultrasonic automatic tracking electrical control box, no need manual adjust the frequency, with power auto compensation function, avoiding the reduction of power after long time use. Could freely adjust the power based on tube material and size, stable and minimum the fault rate, extend the life span than the normal electrical box.
◎ PLC with touch screen control system, providing friendly operation experience.
◎ Made of 304 stainless Steel, acid and alkali resistance, corrosion resistance.
◎ "Panasonic” high sensitive sensor with stepping motor, could track the registration mark precisely.
◎ Table top design, practical and compact.
| Machine Parameters | |||
| Model | HX-007 | Capacity | 10-15pcs/min |
| Frequency | 20kHz | Tube diameter | 13-50mm |
| Power | 2600W | Tube height | 50-210mm |
| Power supply | AC220V/110V | Working pressure | 0.5 MPa |
| Filling Range | / | Size | L850mm*W600mm*H730mm |
| Filling accuracy | / | N.W/G.W | 75kgs |
Application:
Widely used for food, pharmaceutical, cosmetics, chemical and other plastic, PE, aluminum laminated tube filling and sealing.
